AutoCAD Mechanical Essential Training

74 Video Lessons

Was: $25

Deal Price: $15

You Save: $10 (40%)

About this Course

AutoCAD Mechanical includes the very best of AutoCAD along with industry-specific libraries of parts and tools for mechanical engineering, making it a must-learn application for anyone involved in the design and construction of machinery.

Expert covers the basics of the AutoCAD Mechanical 2021 user interface and leads you step-by-step through producing precise, measured mechanical engineering drawings and designs. Expert teaches you how to structure drawings and data, create and edit geometry, generate parts from the library, and annotate drawings.

Plus, expert shows how to perform design calculations for manufacturing, as well as create templates that are customized to suit any workflow.



Topics include:

  • Navigating the interface
  • Managing layers and object properties
  • Structuring, reusing, and editing mechanical data
  • Creating key geometry
  • Adding centerlines and holes
  • Manipulating geometry
  • Inserting parts with part generators
  • Creating drawing sheets
  • Placing dimensions and annotating parts
  • Creating a bill of materials and parts list
  • Calculating design factors
  • Creating a default standard template



Contents



00 - Introduction
Working with AutoCAD Mechanical
What you should know before watching this course
Using the exercise files
The new AutoCAD 2021 interface
Prerequisite courses in the library



01 - Explore the AutoCAD Mechanical User Interface
Explore the AutoCAD Mechanical user Interface
Use the AutoCAD Mechanical ribbon
The enhanced shortcut menu
The Mechanical Browser
Drafting Settings dialog box
Quick Access Toolbar (QAT)



02 - Object Property and Layer Management
Property management
Automatic property management
Layer control and controlling the layer display
Use geometry on layers



03 - Organize Your Mechanical Drawing
Draw creation workflows
Structure your mechanical data in drawings
Create a mechanical drawing using structure
Reuse structured data
Edit structured data



04 - Create Your Key Geometry
Create geometry using the core design tools
Configure and activate Power Snaps
Add centerlines and holes
Add and use construction lines
Design with lines
Add holes and slots
Using the BREAKATPOINT command



05 - Manipulate Mechanical Geometry
Work with basic editing tools
Use power commands
Create and edit associative hides
Create and edit associative hides with structure



06 - Use Mechanical Part Generators
Insert standard parts
Notate standard parts
Use the Content Libraries palette
Design chains and belts
Place a shaft in an assembly
Insert springs into a drawing



07 - Create Mechanical Drawing Sheets
Create viewports and details in layouts
Create drawing sheets in model space
Use annotation views in structure
Insert title blocks and borders
Working with revision clouds



08 - Work with Dimensions and Annotation
Annotate parts
Add different power dimensions
Place multiple dimensions
Edit dimensions
Add hole charts and fits lists
Create a revision list
Using the text layer override



09 - Bill of Materials, Parts Lists, and Balloons
Create part references
Create and edit a bill of materials
Create and edit a bill of materials with structure



10 - Use Design Calculations
Calculate moments of inertia
Calculate the deflection line
Calculate shaft strength
Calculate FEA stresses



11 - Leverage Existing Drawing Data
Demonstrate mechanical content in an AutoCAD Mechanical DWG
Demonstrate mechanical content in an AutoCAD DWG
Create views associated with an Inventor model



12 - Mechanical Options (CAD Manager)
Create and settle a default standard template
Configure layers and object properties
Set annotation properties
Configure BOM, parts list, and balloons
