Quantity Takeoffs for BIM

29 Video Lessons

Was: $20

Deal Price: $10

You Save: $10 (50%)

About this Course

Quantification is a core piece of functionality of Navisworks. Using a 3D model, you can create a highly accurate quantity takeoff that ties it physically to the model. This allows you to see items that have been accounted for and those that have not and make more accurate material estimates. If you don't have a 3D model, don't worry. With this course, you will learn how to take off a 2D sheet set as well.

Expert shows how to set up a takeoff workbook using the built-in catalogs in Navisworks (CSI and Uniformat), use your own custom catalogs, and perform model and virtual takeoffs.

Plus, learn to perform 2D takeoffs from a DWF sheet set.



Contents



Introduction
Welcome

Using the exercise files



1. Project Creation
Selecting the right Navisworks

Breaking down the Quantification dialog

Project setup and docking the dialog

Using the Wizard



2. Catalogs
Using the CSI-16 catalog

Using the CSI-48 catalog

Using the Uniformat catalog

Using no catalog

Importing a custom catalog

Creating and exporting a custom catalog



3. Quantification
Adding a resource

Showing and hiding takeoffs

Applying appearances

Model and virtual takeoffs

Adding viewpoints



4. Object Selection
Using the Selection Tree

Selecting same objects

Searching and grouping objects

Updating groups



5. DWF Takeoff
Usable files

Loading a DWF with a live model

Taking off elements from a DWF

The Sheet Browser

Select and take off objects in a DWF



6. 2D Takeoff
Adding polylines

Adding and backing out areas

Bucket fills

1. Language: English.

2. Secure download.

    Video file format: MP4.

3. Learn anywhere. Switch between

    your computer, tablet, or TV.

4. Practice while you learn

    with exercise files.

5. Secure payment by PayPal.

6. 30 days refund.

7. No subscription needed.

8. Lifetime access.

9. This course without a sponsored ads.



Watch. Listen. Practice. Learn.
